Compaq AlphaServer ES45 1B User Manual

5-28 ES45 Owner's Guide
To run a complete diagnostic test using the test command, the system configu-
ration must include:
• A serial loopback connected to the COM2 port (not included)
• A parallel loopback connected to the parallel port (not included)
• A formatted diskette
• A formatted CD-ROM
The test script tests devices in the following order:
1. Memory tests (one pass)
2. Read-only tests: DK* disks, DU* disks, DR* disks, DQ* disks, DF* disks,
MK* tapes, DV* floppy.
NOTE: You must install media to test disks, tapes, and the floppy drive. Since
no write tests are performed, it is safe to test disks and tapes that con-
tain data.
3. Console loopback tests if -lb argument is specified: COM2 serial port and
parallel port.
4. VGA console tests: These tests are run only if the console environment
variable is set to serial. The VGA console test displays rows of the word
compaq.
5. Network internal loopback tests for EW* networks.

Compaq AlphaServer ES45 1B Specifications

General

Processor Speed	1 GHz
Memory	Up to 32 GB
Memory Type	DDR SDRAM
Expansion Slots	6 PCI slots
Network	Integrated 10/100 Ethernet
Operating System	Tru64 UNIX, OpenVMS
Form Factor	Rackmount
Processor	Alpha EV68
Chipset	Tsunami chipset
Storage	Up to 6 hot-swap SCSI drives
I/O Slots	6 PCI slots
Power Supply	Redundant hot-swap power supplies
