Troubleshooting 7-15
SMB0.CPB0.PCI3 00 DE500-AA N
SMB0.CPB0.PCI5 00 ELSA GLori
SMB0.CPB0.PCI7 00 DEGPA-SA
SMB0.CPB0.PCI8 00 DEGPA-SA
SMB0.CPB0.PCI9 00 NCR 53C895
OCP0 00 70-33894-0x - OCP
PWR0 00 30-49448-01. C05 30-49448-0 API-76 7f
PWR1 00 30-49448-01. C05 30-49448-0 API-76 7f
PWR2 00 30-49448-01. C05 30-49448-0 API-76 7f
FAN1 00 70-40073-01 - Fan
FAN2 00 70-40073-01 - Fan
FAN3 00 70-40072-01 - Fan
FAN4 00 70-40071-01 - Fan
FAN5 00 70-40073-02 - Fan
FAN6 00 70-40074-01 - Fan
P00>>>
Example 7–6 Show Fru Command
FRUname The FRU name recognized by the SRM console. The name also
indicates the location of that FRU in the physical hierarchy.
SMB = system board; CPU = CPUs; MMB = memory motherboard;
DIM = DIMMs; CPB = PCI backplane; PCI = PCI option; SBM =
SCSI backplane; PWR = power supply; FAN = fans; JIO= I/O
connector module (junk I/O).
E Error field. Indicates whether the FRU has any errors logged
against it. FRUs without errors show 00 (hex).
FRUs with errors
have a non-zero value that represents a bit mask of possible errors.
See Table 7–4.
Part # The part number of the FRU in ASCII, either a Compaq part number
or a vendor part number.
Serial # The serial number. For Compaq FRUs, the serial number has the
form XXYWWNNNNN.
XX = manufacturing location code
YWW = year and week
NNNNN = sequence number. For vendor FRUs, the 4-byte sequence
number is displayed in hex.
Other Optional data. For Compaq FRUs, the Compaq part alias number (if
one exists). For vendor FRUs, the year and week of manufacture.
Misc. Miscellaneous information about the FRUs. For Compaq FRUs, a
model name, number, or the common name for the entry in the Part
# field. For vendor FRUs, the manufacturer's name.
