CRS-300 1:10 Redundancy Switch MN/CRS300.IOM
Front Panel Operation Revision 19
6–18
► For the CDM-600/L modem, the code is the hex value of the position of the fault parameter
within the MGC configuration code.
00
NO ERROR
01
TFQ
Tx Frequency
09
TDR
Tx Data Rate
12
TFT
Tx FEC Type
13
TRS
Tx Reed Solomon type
14
TCR
Tx FEC Code Rate
15
TMD
Tx Modulation
16
TSI
Tx Spectrum Inversion
17
TSC
Tx Scrambler state
18
TPL
Tx Power Level
1C
AUP
AUPC enable
1D
APP
AUPC parameters
23
TCK
Tx Clock source
24
TXO
Tx Carrier state
25
TIT
Tx Interface Type
26
TTC
Tx Ternary Code
27
TFM
Tx Framing Mode
28
TIP
Tx IF Impedance
29
RFQ
Rx Frequency
31
RDR
Rx Data Rate
3A
RFT
Rx FEC Type
3B
RRS
Rx Reed Solomon type
3C
RCR
Rx FEC Code Rate
3D
RMD
Rx Modulation
3E
RSI
Rx Spectrum Inversion
3F
RDS
Rx Descrambler state
40
RSW
Rx Sweep Width
42
RCK
Rx Clock source
43
EBA
EbNo Alarm point
47
RBS
Rx Buffer Size
4C
RIT
Rx Interface Type
4D
RTC
Rx Ternary Code
4E
RFM
Rx Framing Mode
4F
RIP
Rx IF Impedance
50
EFM
Unit EDMAC Mode
51
ESA
EDMAC Slave Address
55
TST
Unit Test Mode
56
MSK
Unit Alarm Mask
5C
EFR
External Freq Ref
5D
SSI
Statistics Sampling Interval
5E
RTE
Rx Terrestrial Alarm Enable
5F
TTA
Tx Terrestrial Alarm Mask
60
ODU
ODU comms Enable
61
TBA
Tx Backward Alarms
65
RBA
Rx Backward Alarms
69
TVL
Tx audio Volume
6D
RVL
Rx audio Volume
71
DTY
Drop Type
72
ITY
Insert Type
73
TET
Tx ESC Type - 64k or 2 audio
74
RET
Rx ESC Type - 64k or 2 audio
75
ITD
Invert Tx Data
76
IRD
Invert Rx Data
SWITCH ALARM: MODEM COMMS
PROBLEM, POSITION 2
There is a fault. There is a problem with the I/O communications with Traffic Modem 2. The
“Unit Status” front panel LED will be RED.
Suggestions:
• Check cable connections – see Chapter 4. CABLES AND CONNECTIONS.
• Check modem configurations – see Chapter 5. MODEM, RMI/TMI, AND SWITCH
CONFIGURATION.
SWITCH ALARM: TMI: I/F
MISMATCH, POSITION 2
There is a fault. There is a mismatch of data interface type between what has been selected in
the modem menu and the TMI type that is connected to that Traffic Modem. The “Unit Status”
front panel LED will be RED.
Suggestion: Ensure the modem interface type is compatible with the TMI being used. The
CDM-600/Ls and CDM-625/As have both TX and RX interface types. CDM-570/As and
CDM-570L/ALs have only one unit interface type each. Either edit the modem interface
setting(s) or swap the TMI.
