Wireless Controller CLI Reference Guide
122
4
exit
Save vpn policy configuration
changes and exit current mode.
5
general_policy_type
Setting policy manual or auto
vpn policy type
6
general_ike_version
Setting version ikev1 or ikev2
IPsec VPN IKE Version
7
general_ip_protocol_version
Setting protocol version ipv5 or ipv6
8
general_ipsec_mode
Setting ipsec mode for the vpn policy
VPN ipsec modes
9
general_select_local_gateway
Setting local gatew ay for the vpn
policy
VPN gateway
10
general_remote_end_point_type
Set mode to IP address or Internet
Name/FQDN of the remote gatew ay
or client PC
vpn remote end point type
11
general_remote_end_point
The IP address or Internet
Name/FQDN of the remote gatew ay
or client PC.
12
general_remote_end_point
ip_address
The IP address of the remote
gatew ay or client PC.
13
general_remote_end_point fqdn
The IP address or Internet
Name/FQDN of the remote gatew ay
or client PC.
String
14
general_enable_mode_config
enable/disable mode config
Boolean choice
15
general_enable_netbios
enable/disable this to allow NetBIOS
broadcasts to travel over the VPN
tunnel.
Boolean choice
16
general_enable_rollover
enable/disable rollover
Boolean choice
17
general_protocol
Setting protocol esp or ah
IPsec VPN Protocol
18
general_enable_dhcp
enable/disable dhcp.
Boolean choice
19
general_local_network_type
Select the IP addresses on the local
side that w ill be part of the tunnel.
This can be either a single IP
address, several IP addresses in a
range, an entire subnet, or any IP
address that w ants to connect
vpn netw ork type
20
general_local_start_address
IP address from w here the range
needs to begin
21
general_local_end_address
IP address w here the range needs to
end
22
general_local_subnet_mask
Subnet mask of the subnet used
IP address AAA.BBB.CCC.DDD w here
each part is in the range 0-255
23
general_local_prefix_length
Prefix length of the ipv6 subnet used
IPv6 Prefix length
24
general_remote_netw ork_type
Select the IP addresses on the
remote side that w ill be part of the
tunnel. This can be either a single IP
address, several IP addresses in a
range, an entire subnet, or any IP
address that w ants to connect
vpn netw ork type
25
general_remote_start_address
IP address from w here the range
needs to begin
26
general_remote_end_address
IP address w here the range needs to
end
27
general_remote_subnet_mask
Subnet mask of the subnet used
IP address AAA.BBB.CCC.DDD w here
each part is in the range 0-255
28
general_remote_prefix_length
Prefix length of the ipv6 subnet used
