10% duty cycle, horizontal braking, T6
FC 202 Horizontal braking 10% duty cycle
Adjustable frequency drive data
Brake resistor data Installation
R
rec
[Ω]
P
br,cont.
[kW (hp)]
Danfosspart number Cable
cross-
section
[mm
2
(AWG)]
Thermo
relay
[A]
Line
power
type
P
m
[kW
(hp)]
R
min
[Ω]
R
br,nom
[Ω]
Wire IP54
Screw
terminal
IP21
Screw
terminal
IP65
Bolt
connection
IP20
T6 0.75 (1.0) 620 1329.7 1200
0.100
(0.134)
175u3000 - - - 1.5 (16) 0.3
T6 1.1 (1.5) 620 889.1 850
0.100
(0.134)
175u3001 - - - 1.5 (16) 0.4
T6 1.5 (2) 550 642.7 570
0.100
(0.134)
175u3003 - - - 1.5 (16) 0.4
T6 2.2 (3) 380 431.1 415
0.200
(0.268)
175u3005 - - - 1.5 (16) 0.7
T6 3 (4) 260 312.5 270
0.200
(0.268)
175u3007 - - - 1.5 (16) 0.8
T6 4 (5) 189 231.6 200
0.300
(0.402)
175u3342 - - - 1.5 (16) 1.1 (1.5)
T6 5.5 (7.5) 135 166.6 145
0.450
(6.032)
175u3343 175u3012 175u3013 - 1.5 (16) 1.7
T6 7.5 (10) 99.0 121.1 100
0.570
(0.764)
175u3344 175u3136 175u3137 - 1.5 (16) 2.3
T6 11 (15) 69.0 81.6 72
0.680
(0.912)
175u3345 175u3456 175u3455 - 1.5 (16) 2.9
T6 15 (20) 48.6 59.4 52
1.130
(1.515)
175u3346 175u3458 175u3457 - 1.5 (16) 4.4
T6 25 (18.5) 35.1 47.9 38
1.400
(1.877)
175u3347 175u3460 175u3459 - 1.5 (16) 5.7
T6 22 (30) 27.0 40.1 31
1.700
(2.279)
175u3348 175u3037 175u3038 - 1.5 (16) 7
T6 30 (40) 22.5 29.2 27
2.200
(2.949)
175u3349 175u3043 175u3044 - 1.5 (16) 8.5
T6 37 (50) 17.1 23.6 19
2.800
(3.753)
175u3350 175u3462 175u3461 - 2.5 (14) 11.4
T6 45 (60) 13.5 19.4 14
3.200
(4.289)
175u3358 175u3464 175u3463 - 2.5 (14) 14.2
T6 55 (75) 11.7 15.8 13.5
4.200
(5.630)
- 175u3057 175u3058 - 4 (12) 17
T6 75 (100) 9.9 11.5 11
5.500
(7.373)
- 175u3063 175u3064 - 6 21
T6 90 (125) 8.6 9.6 7.0
7.000
(9.383)
- - - 175u3245 10 (8) 32
Table 6.11 T6, Horizontal Braking 10% Duty Cycle, Recommended Brake Resistors
Type code and Selection
VLT
®
AQUA Drive FC 202
