1 Passive harmonic filter (PHF)
3 Non-fusible disconnect
5 Molded-case circuit breaker (MCCB)
7 dU/dt filter
9 Sine-wave filter
2 Line reactor
4 Fusible disconnect
6 Contactor
8 Common-mode filter
10 Drive module (varies in power rating)
Illustration 5: Visual Representation of a D10h Enclosure and the Locations of Available Options
