Danfoss VLT AQUA Drive FC 202 User Manual

Table 47: Recommended Fuse Ratings for UL Installation, 525–690 V
Drive model Fuse P/N Maximum
current [A]
Cutoff cur-
rent [A]
Peak let thru
[A]
Maximum
fuse rating F1
[A]
Minimum
voltage rat-
ing [V]
Class F1
N110 Mersen A4J300 175 2400 5400 175 600 Class L
N132 Mersen A4J350 200 2700 6 200 600 Class L
N160 Mersen A4J400 250 3200 7500 250 600 Class L
N200 Mersen A4J500 350 4600 10000 350 600 Class L
N250 Mersen A4J600 400 5000 10400 400 600 Class L
N315 Mersen AABY750 500 8000 11500 500 600 Class L
N400 Mersen A4BY800 600 9000 12000 600 600 Class L
N450 Mersen A4BY1000 600 9000 12000 600 600 Class L
N500 Mersen A4BY1000 650 11500 28000 750 600 Class L
N560 Mersen A4BY1200 750 11500 28000 750 600 Class L
N6300 Mersen A4BY1200 800 12000 28000 800 600 Class L
N710 Mersen A4BY1200 1000 15000 35000 1000 600 Class L
N800 Mersen A4BY1200 1100 18500 42000 1100 600 Class L
5.10 Enabling Motor Operation
Context:
If the status line at the bottom of the LCP reads AUTO REMOTE COAST, the unit is ready to operate but is missing an input signal from
terminal XD2.14 in the control compartment. Digital input terminal XD2.14 is designed to receive a 24 V DC external interlock
command that allows the drive to operate when using factory default programming values.
NOT I C E
FACTORY-INSTALLED OPTIONAL EQUIPMENT
Do not remove factory-installed wiring to terminal XD2.14. If the drive does not run, refer to the documentation for the
optional equipment that is wired into terminal XD2.14.
Procedure
1. When no interlock device is used, use a push-in type jumper (WAGO 2002-433) between terminal XD2.11 and XD2.14 in the control
compartment. This wire provides an internal 24 V signal on terminal XD2.14. The drive is ready for operation.
5.11 Selecting the Voltage/Current Input Signal
Context:
The analog input terminals XD2.7 and XD2.8 in the control compartment allow setting of input signal to voltage (0–10 V) or current
(0/4–20 mA).
Electrical Installation
Operating Guide | VLT® AQUA Drive FC 202
AQ262141056213en-000101 / 130R0882
94 | Danfoss A/S © 2018.10
