The current ratings for the E5h and E6h enclosures are achieved by filter paralleling.
Table 88: dU/dt Filter Configurations for D9h–D10h and E5h–E6h Enclosures, 380–480 V
Enclosure Model Current rating [A] Filters required
D9h N110 261 1
D9h N132 261 1
D9h N160 418 1
D10h N200 418 1
D10h N250 590 1
D10h N315 590 1
E5h N355 418 2
E5h N400 418 2
E5h N450 418 2
E6h N500 590 2
E6h N560 590 2
Table 89: dU/dt Filter Configurations for D9h–D10h and E5h–E6h Enclosures, 525–690 V
Enclosure Model Current rating [A] Filters required
D9h N110 144 1
D9h N132 261 1
D9h N160 261 1
D10h N200 418 1
D10h N250 418 1
D10h N315 418 1
D10h N355 418 1
E5h N400 590 1
E5h N500 418 2
E5h N560 418 2
E5h N630 418 2
E6h N710 590 2
E6h N800 590 2
10.7.4 Sine-wave Filter Specifications
Voltage rating 3x380–480 V and 525–690 V AC
Nominal current @ 50 Hz
212 A and 315 A for 380–480 V, 137 A and 222 A for 525–690 V
(1)
Specifications
Operating Guide | VLT® AQUA Drive FC 202
AQ262141056213en-000101 / 130R0882
178 | Danfoss A/S © 2018.10
