11.6.7 Sine-wave Filter Losses
Table 134: Power Losses for Sine-wave Filter Option, 380–500 V (Losses Shown in Watts)
Model 380–440 V 441–500 V
– NO HO NO HO
N90K 1320 920 1060 752
N110 1363 906 1161 728
N132 2000 1363 1838 1161
N160 2291 1457 1914 1339
N200 2322 1572 1978 1313
N250 3484 2322 2885 1978
N315 3179 2643 2556 2141
N355 4075 3179 3375 2556
N400 4699 3547 3913 3375
N450 3902 3225 3066 2685
N500 4939 3902 3991 3066
Table 135: Power Losses for Sine-wave Filter Option, 525–690 V (Losses Shown in Watts)
Model 525–550 V 551–690 V
– NO HO NO HO
N90K 1100 748 1006 684
N110 1065 762 975 696
N132 1640 1065 1496 975
N160 1876 1184 1716 1080
N200 1863 1299 1706 1188
N250 2630 1863 2401 1706
N315 3545 2630 3246 2401
N355 3237 2286 2967 2116
N400 4004 2697 3663 2463
N500 3603 2772 3296 2536
N560 4027 3603 4027 3296
N630 5909 4406 5406 4027
N710 8018 5906 7330 5406
Appendix
Operating Guide | VLT® AQUA Drive FC 202
AQ262141056213en-000101 / 130R0882
204 | Danfoss A/S © 2018.10
