Table 94: Panel Fuses for N710–N800 Models, 525–690 V
N710 N800
IEC (Type gG) 1000 A/690 V 1000 A/690 V
ABB P/N OFAA4AGG1000 OFAA4AGG1000
UL (Class J/L/T) 1000 A/600 V 1100 A/600 V
Mersen P/N A4BY1000 A4BY1100
10.8.3 Fusible Disconnect Switches
The fusible disconnector switch is an option that safely isolates the drive from the mains with a fuse switch mounted below the drive
module. All units ordered and supplied with a factory-installed fusible disconnect switch have a fuse built in to the switch. The fuse has
been sized to meet 65kA SCCR for the system. The input voltage and power rating of the drive determines the specific class or gG fuse.
The input voltage and power rating are found on the name plate. See 4.1 Items Supplied.
Table 95: Fusible Disconnect Switches for N110–N315 Models, 380–480 V
N110 N132 N160 N200 N250 N315
IEC 400 A/690 V 400 A/690 V 400 A/690 V 630 A/690 V 630 A/690 V 630 A/690 V
ABB P/N OS400D30P OS400D30P OS400D30P OS630D30P OS630D30P OS630D30P
UL 400 A/600 V 400 A/600 V 400 A/600 V 600 A/600 V 600 A/600 V 800 A/600 V
ABB P/N OS400J30 OS400J30 OS400J30 OS600J30 OS600J30 OS800L30
Table 96: Fusible Disconnect Switches for N355–N560 Models, 380–480 V
N355 N400 N450 N500 N560
IEC 1250 A/690 V 1250 A/690 V 1250 A/690 V 1250 A/690 V 1250 A/690 V
ABB P/N OS1250D30P OS1250D30P OS1250D30P OS1250D30P OS1250D30P
UL 800 A/600 V 1200 A/600 V 1200 A/600 V 1200 A/600 V 1200 A/600 V
ABB P/N OS800L30 OS1200L30 OS1200L30 OS1200L30 OS1200L30
Table 97: Fusible Disconnect Switches for N110–N315 Models, 525–690 V
N110 N132 N160 N200 N250 N315
IEC 400 A/690 V 400 A/690 V 400 A/690 V 630 A/690 V 630 A/690 V 630 A/690 V
ABB P/N OS400D30P OS400D30P OS400D30P OS630D30P OS630D30P OS630D30P
UL 400 A/600 V 400 A/600 V 400 A/600 V 400 A/600 V 400 A/600 V 600 A/600 V
ABB P/N OS400J30 OS400J30 OS400J30 OS400J30 OS400J30 OS600J30
Table 98: Fusible Disconnect Switches for N400–N630 Models, 525–690 V
N400 N450 N500 N560 N630
IEC 630 A/690 V 630 A/690 V 1250 A/690 V 1250 A/690 V 1250 A/690 V
Specifications
Operating Guide | VLT® AQUA Drive FC 202
AQ262141056213en-000101 / 130R0882 | 181
Danfoss A/S © 2018.10
