Danfoss VLT AQUA Drive FC 202 User Manual

Table 13: Door-mounted Option Codes
Character posi-
tion
Option
code
Description
28–29 XX None
D1 Indicator lights and reset button
D2 Emergency switch off + emergency push-button
D3 STO w/ emergency push-button (no functional safety)
D4 STO/SS1 w/ emergency push-button + safely limited speed (TTL encoder)
D5 STO/SS1 w/ emergency push-button + safely limited speed (HTL encoder)
DA Indicator lights and reset button + emergency switch off and emergency push-button
DB Indicator lights and reset button + STO w/ emergency push-button (no functional safety)
DC Indicator lights and reset button + STO/SS1 w/ emergency push-button + safely limited speed
(TTL encoder)
DE Indicator lights and reset button + STO/SS1 w/ emergency push-button + safely limited speed
(HTL encoder)
3.5 Power Ratings and Dimensions for D9h–D10h and E5h–E6h Enclosures
Table 14: Power Ratings and Dimensions for D9h–D10h and E5h–E6h Enclosures (Standard Configurations)
Enclosed drive D9h D10h E5h E6h
Rated power at 380–480 V [kW (hp)] 110–160 (150–
250)
200–315 (300–450) 355–450 (500–600) 500–560 (650–750)
Rated power at 525–690 V [kW (hp)] 110–160 (125–
200)
200–400 (250–400) 450–630 (450–650) 710–800 (750–950)
Protection rating IP21 (NEMA 1)/
IP54 (NEMA 12)
IP21 (NEMA 1)/IP54
(NEMA 12)
IP21 (NEMA 1)/IP54
(NEMA 12)
IP21 (NEMA 1)/IP54
(NEMA 12)
Drive cabinet D9h D10h E5h E6h
Height [mm (in)]
(1)
2100 (82.7) 2100 (82.7) 2100 (82.7) 2100 (82.7)
Width [mm (in)]
(2)
400 (15.8) 600 (23.6) 600 (23.6) 800 (31.5)
Depth [mm (in)] 600 (23.6) 600 (23.6) 600 (23.6) 600 (23.6)
Weight [kg (lb)]
(2)
280 (617) 355 (783) 400 (882) 431 (950)
Input filter cabinet D9h D10h E5h E6h
Height [mm (in)]
(1)
2100 (82.7) 2100 (82.7) 2100 (82.7) 2100 (82.7)
Width [mm (in)] 400 (15.8) 400 (15.8)/600 (23.6) 600 (23.6) 600 (23.6)/800 (31.5)
Depth [mm (in)] 600 (23.6) 600 (23.6) 600 (23.6) 600 (23.6)
Weight [kg (lb)] 410 (904) 410 (904)/530
(1168)
530 (1168) 530 (1168)/955
(2105)
Input power options cabinet D9h D10h E5h E6h
Product Overview
Operating Guide | VLT® AQUA Drive FC 202
AQ262141056213en-000101 / 130R0882
24 | Danfoss A/S © 2018.10
