11.6.6 dU/dt Filter Losses
Table 132: Power Losses for dU/dt Filter Option, 380–500 V (Losses Shown in Watts)
Model 380–440 V 441–500 V
NO HO NO HO
N90K 350 244 281 199
N110 526 350 448 281
N132 327 223 300 190
N160 514 327 429 300
N200 834 565 710 472
N250 1251 834 1036 710
N315 713 593 573 480
N355 914 713 757 573
N400 1054 795 878 757
N450 1402 1158 1101 964
N500 1774 1402 1434 1101
Table 133: Power Losses for dU/dt Filter Option, 525–690 V (Losses Shown in Watts)
Model 525–550 V 551–690 V
NO HO NO HO
N90K 453 308 414 281
N110 204 146 187 134
N132 314 204 287 187
N160 498 314 456 287
N200 302 211 277 193
N250 427 302 390 277
N315 575 427 527 390
N355 800 565 733 523
N400 989 666 905 608
N500 585 450 535 412
N560 654 585 654 535
N630 959 715 878 654
N710 1430 1054 1308 964
Appendix
Operating Guide | VLT® AQUA Drive FC 202
AQ262141056213en-000101 / 130R0882 | 203
Danfoss A/S © 2018.10
