Drive model Fuse P/N Fuse size Rated cur-
rent [A]
Minimum
SCCR [kA]
Maximum
fuse rating F1
[A]
Minimum
voltage rat-
ing [V]
Type F1
N250 Mersen NH3GG69V355 3 355 8.5 355 690 gG/gL
N315 Mersen NH3GG69V425 3 425 9.5 425 690 gG/gL
N400 Mersen NH3GG69V500 3 500 12 500 690 gG/gL
N450 Mersen NH3GG69V500 3 500 12 500 690 gG/gL
N500 Mersen NH4GG69V630 4 630 14 630 690 gG/gL
N560 Mersen NH4GG69V800 4 800 19 800 690 gG/gL
N630 Mersen NH4GG69V800 4 800 19 800 690 gG/gL
N710 ABB OFAA4GG1000 4 1000 25 1000 690 gG/gL
N800 ABB OFAA4GG1000 4 1000 25 1000 690 gG/gL
5.9.3 Recommended Fuse Ratings for UL Installation
The table values are calculated using correction factors for a 40 °C (104 °F) ambient operating condition and using cables with a
minimum insulation rating of 90 °C (194 °F).
UL Approval is valid for maximum input voltage of 600 V. Per UL508A, the short-circuit current rating (SCCR) is as follows:
• Enclosed drives with a fusible disconnect or fusible disconnect and contactor option have 65 kA SCCR at the rated voltage.
• Enclosed drives with single switchgear (mains contactor only or non-fusible disconnect only option) have a 5 kA SCCR, but can
reach 65 kA if the recommended Class fuses are used upstream.
• Enclosed drives with the MCCB option have a 65 kA interrupting rating for 380–480 V, and a 50 kA interrupting rating for525–690 V.
Table 46: Recommended Fuse Ratings for UL Installation, 380–480 V
Drive mod-
el
Fuse P/N Maximum
current [A]
Cutoff cur-
rent [A]
Peak let thru
[A]
Maximum
fuse rating F1
[A]
Minimum
voltage rat-
ing [V]
Class F1
N110 Mersen A4J300 300 4000 9000 300 500 Class J
N132 Mersen A4J350 350 4600 10000 350 500 Class J
N160 Mersen A4J400 400 5000 10400 400 500 Class J
N200 Mersen A4J500 500 8000 11500 500 500 Class J
N250 Mersen A4J600 600 9000 12000 600 500 Class J
N315 Mersen AABY750 750 11500 28000 750 500 Class J
N355 Mersen A4BY800 800 12000 28000 800 500 Class J
N400 Mersen A4BY1000 1000 15000 35000 1000 500 Class J
N450 Mersen A4BY1000 1000 15000 35000 1000 500 Class J
N500 Mersen A4BY1000 1100 18500 42000 1100 500 Class J
N560 Mersen A4BY1200 1200 19000 42000 1200 500 Class J
Electrical Installation
Operating Guide | VLT® AQUA Drive FC 202
AQ262141056213en-000101 / 130R0882 | 93
Danfoss A/S © 2018.10
