10.9.5 E6h Enclosed Drive Dimensions
e30bu145.10
800 (31.5)
2000
55
(78.7)
1200 (82.7)
(2.2)
1
6
600 (23.6)
2
4
5
600 (23.6)
3
100
(3.9)
400
(15.8)
1 Passive harmonic filter/line reactor cabinet
3 E6h drive cabinet
5 dU/dt cabinet
2 Options cabinet
4 Sine-wave cabinet
6 Standard pedestal
Illustration 75: Dimensions for E6h Enclosure with Standard Pedestal
