-RF2 Sine-wave filter inductor
-RF1 dU/dt filter inductor
-RF3 Common-mode filter
-TA1 Drive module
-CA4 Sine-wave filter capacitor
-CA3 dU/dt filter capacitor
-MA1 Motor (customer side)
LCP Local control panel
Illustration 78: Electrical Power Flow for E5h/E6h Enclosure
11.6 Input Power Option Losses
11.6.1 Contactor Losses
Table 122: Power Losses for Contactor Option, 380–500 V (Losses Shown in Watts)
Model 380–440 V 441–500 V
– NO HO NO HO
N90K 16 11 13 9
N110 25 16 21 13
N132 36 25 33 21
N160 57 36 47 33
N200 42 28 36 24
N250 63 42 52 36
N315 62 51 50 42
N355 79 62 66 50
N400 91 69 76 66
N450 74 61 58 51
N500 94 74 76 58
Table 123: Power Losses for Contactor Option, 525–690 V (Losses Shown in Watts)
Model 525–550 V 551–690 V
– NO HO NO HO
N90K 7 5 6 4
N110 10 7 9 6
N132 15 10 13 9
N160 23 15 21 13
N200 33 23 30 21
N250 47 33 43 30
N315 63 47 58 43
N355 40 28 37 26
N400 50 33 45 30
