Pulse input accuracy (0.1–1 kHz) Maximum error: 0.1% of full scale
Encoder input accuracy (1–11 kHz) Maximum error: 0.05% of full scale
1
FC 302 only.
2
Encoder inputs: XD2.16=A, XD2.17=B.
The pulse and encoder inputs (terminals XD2.15, XD2.16, XD2.17) are galvanically isolated from the supply voltage (PELV) and other
high-voltage terminals.
10.6.8 Control Characteristics
Resolution of output frequency at 0–590 Hz ±0.003 Hz
Repeat accuracy of precise start/stop (terminals XD2.12, XD2.13) ≤±0.1 ms
System response time (terminals XD2.12, XD2.13, XD2.14, XD2.15, XD2.16, XD2.17) ≤2 ms
Speed control range (open loop) 1:100 of synchronous speed
Speed control range (closed loop) 1:1000 of synchronous speed
Speed accuracy (open loop) 30–4000 RPM: Error ±8 RPM
Speed accuracy (closed loop), depending on resolution of feedback device 0–6000 RPM: Error ±0.15 RPM
Torque control accuracy (speed feedback) Maximum error ±5% of rated torque
All control characteristics are based on a 4-pole, asynchronous motor.
10.6.9 Relay Outputs
Programmable relay outputs FC 302: 2
Relay 01 terminal number
(1)
21–23 (break), 21–22 (make)
Maximum terminal load (AC-1) on 21–23 (NC), 21–22 (NO) (resistive load)
(2) (3)
240 V AC, 2 A
Maximum terminal load (AC-15) (inductive load @ cosφ 0.4) 240 V AC, 0.2 A
Maximum terminal load (DC-1) on 21–22 (NO), 21–23 (NC) (resistive load) 60 V DC, 1 A
Maximum terminal load (DC-13) (inductive load) 24 V DC, 0.1 A
Relay 02 (FC 302 only) terminal number
(1)
24–26 (break), 24–25 (make)
Maximum terminal load (AC-1) on 24–25 (NO) (resistive load)
(2) (3)
400 V AC, 2 A
Maximum terminal load (AC-15) on 24–25 (NO) (inductive load @ cosφ 0.4) 240 V AC, 0.2 A
Maximum terminal load (DC-1) on 24–25 (NO) (resistive load) 80 V DC, 2 A
Maximum terminal load (DC-13) on 24–25 (NO) (inductive load) 24 V DC, 0.1 A
Maximum terminal load (AC-1) on 24–26 (NC) (resistive load) 240 V AC, 2 A
Maximum terminal load (AC-15) on 24–26 (NC) (inductive load @ cosφ 0.4) 240 V AC, 0.2 A
Maximum terminal load (DC-1) on 24–26 (NC) (resistive load) 50 V DC, 2 A
Maximum terminal load (DC-13) on 24–26 (NC) (inductive load) 24 V DC, 0.1 A
Minimum terminal load on 21–23 (NC), 21–22 (NO), 24–26 (NC), 24–25 (NO) 24 V DC 10 mA, 24 V AC 20 mA
Environment according to EN 60664-1 Overvoltage category III/pollution degree 2
1
IEC 60947 parts 4 and 5. The relay contacts are galvanically isolated from the rest of the circuit by reinforced isolation (PELV).
2
Overvoltage category II.
3
UL applications 300 V AC 2 A.
Specifications
Operating Guide | VLT® AQUA Drive FC 202
AQ262141056213en-000101 / 130R0882
174 | Danfoss A/S © 2018.10
