Page #20 background image
5 Mains voltage
4 = 380–480 V
5 = 380–500 V
6 = 525–690 V
7 Build date (wwy, where ww = the week and y = the last digit
of the year)
Illustration 7: Using the Nameplate to Find the Enclosure Size and Installed Options
3.4.2 Enclosure Size Identification
Table 3: Model by Drive Voltage
Model Enclosure size (380–480 V) Enclosure size (525–690 V)
N110 D9h D9h
N132 D9h D9h
N160 D9h D9h
N200 D10h D10h
N250 D10h D10h
N315 D10h D10h
N355 E5h
N400 E5h D10h
N450 E5h E5h
N500 E6h E5h
N560 E6h E5h
N630 E5h
N710 E6h
N800 E6h
3.4.3 Option Code Identification
Table 4: Low-harmonic Filter Option Codes
Character position Option code Description
7 T None
A Active filter
P Passive filter, THDi=5%, 50 Hz
H Passive filter, THDi=8%, 50 Hz
L Passive filter, THDi=5%, 60 Hz
U Passive filter, THDi=8%, 60 Hz
Product Overview
Operating Guide | VLT® AQUA Drive FC 202
AQ262141056213en-000101 / 130R0882
20 | Danfoss A/S © 2018.10
