Page #69 background imageLoading...
Page #69 background image
XD2 ter-
minal
Parameter Default setting Description
19 STO When not using the optional STO feature, a jumper wire is re-
quired between terminal 10 (or 11) and terminal 19. This set-
up allows the drive to operate with factory default program-
ming values.
Table 27: Analog Input/Output Terminal Descriptions
XD2 termi-
nal
Parameter Default setting Description
4 Common for analog output.
5 Parameter 6-50 Terminal 42 Out-
put
[0] No operation Programmable analog output. 0–20 mA or 4–20 mA at a maxi-
mum of 500 Ω.
6 +10 V DC 10 V DC analog supply voltage for potentiometer or thermis-
tor. 15 mA maximum.
7 Parameter group 6-1* Analog In-
put 1
Reference Analog input. For voltage (V) or current (mA).
8 Parameter group 6-2* Analog In-
put 2
Feedback
9 Common for analog input.
5.7.4 Relay Terminals
Table 28: Relay Terminal Descriptions
XD2 terminal Parameter Default setting Description
21, 22, 23 Parameter 5-40 Function Relay [0] [0] No operation Form C relay outputs. For AC or DC voltage.
24, 25, 26 Parameter 5-40 Function Relay [1] [0] No operation
5.7.5 Option Card Terminals
The option cards extend the functionality of drives and provide a high variety of interfaces to automation systems. When the option
cards are specified in the type code, they are mounted in slots A, B, C, and D of the control card within the drive module. The option
card wiring is routed to a terminal block within the control compartment. For more details, refer to the installation/operating guide for
the respective option card.
NOTI C E
OPTION CARD INSTALLATION
If the option card is ordered along with the drive using the type code, the factory installs the option card and its wiring. If the
option is ordered separately, the customer is responsible for installing the option card and the wiring extensions to the control
compartment.
Electrical Installation
Operating Guide | VLT® AQUA Drive FC 202
AQ262141056213en-000101 / 130R0882 | 69
Danfoss A/S © 2018.10
