Table 29: Option A Terminal Connections
Option card terminal Corresponding terminal within the control compartment
1 XD2.40
2 XD2.41
3 XD2.42
4 XD2.43
5 XD2.44
Table 30: Option B Terminal Connections
Option card terminal Corresponding terminal within the control compartment
1 XD2.46
2 XD2.47
3 XD2.48
4 XD2.49
5 XD2.50
6 XD2.51
7 XD2.52
8 XD2.53
9 XD2.54
10 XD2.55
11 XD2.56
12 XD2.57
Table 31: Option C1 Terminal Connections
Option card terminal Corresponding terminal within the control compartment
X46.1 XDF.1
X46.2 XDF.2
X46.3 XDF.3
X46.4 XDF.4
X46.5 XDF.5
X46.6 XDF.6
X46.7 XDF.7
X46.8 XDF.8
X46.9 XDF.9
X46.10 XDF.10
X46.11 XDF.11
