Option card terminal Corresponding terminal within the control compartment
X46.12 XDF.12
X46.13 XDF.13
X46.14 XDF.14
X58.1 XDF.15
X58.2 XDF.16
X45.1 XDF.17
X45.2 XDF.18
X45.3 XDF.19
X45.4 XDF.20
X47.1 XDF.21
X47.2 XDF.22
X47.3 XDF.23
X47.4 XDF.24
X47.5 XDF.25
X47.6 XDF.26
X47.7 XDF.27
X47.8 XDF.28
X47.9 XDF.29
X47.10 XDF.30
X47.11 XDF.31
X47.12 XDF.32
Table 32: Option D Terminal Connections
Option card terminal Corresponding terminal within the control compartment
35 XD2.28
36 XD2.29
