Danfoss VLT AQUA Drive FC 202 User Manual

Enclosure Model Line reactor [A]
E5h N355 2x425
N400 2x425
N450 2x425
E6h N500 3x425
N560 3x425
Table 87: Line Reactor Configuration for D9h–D10h and E5h–E6h Enclosures, 525–690 V
Enclosure Model Line reactor [A]
D9h N110 225
N132 225
N160 225
D10h N200 315
N250 315
N315 2x225
N400 2x225
E5h N450 2x315
N500 2x315
N560 2x315
N630 3x225
E6h N710 3x315
N800 3x315
10.7.3 dU/dt Filter Specifications
Voltage rating 3x380–690 V
Nominal current @ 50 Hz
Up to 590 A
(1)
Motor frequency derating, 50 Hz Nominal
Motor frequency derating, 60 Hz Nominal
Motor frequency derating, 100 Hz 0.75 x nominal
Minimum switching frequency No limit
Maximum switching frequency Nominal switching frequency
Overload capacity 150% for 60 s, every 10 minutes.
Ambient temperature [°C (°F)] -10 (14) to +45 (113)
Storage temperature [°C (°F)] -25 (-13) to +60 (150)
Transport temperature [°C (°F)] -25 (-13) to +70 (158)
Maximum ambient temperature with derating [°C (°F)] 55 (131)
Maximum altitude without derating [°C (°F)] –
Specifications
Operating Guide | VLT® AQUA Drive FC 202
AQ262141056213en-000101 / 130R0882 | 177
Danfoss A/S © 2018.10
