Voltage level at digital/frequency output 0–24 V
Maximum output current (sink or source) 40 mA
Maximum load at frequency output 1 kΩ
Maximum capacitive load at frequency output 10 nF
Minimum output frequency at frequency output 0 Hz
Maximum output frequency at frequency output 32 kHz
Accuracy of frequency output Maximum error: 0.1% of full scale
Resolution of frequency outputs 12 bit
1
Can also be programmed as input.
The digital output is galvanically isolated from the supply voltage (PELV) and other high-voltage terminals.
10.6.6 Digital Inputs
Programmable digital inputs 4 (6)
Terminal number
(1)
XD2.12, XD2.13, XD2.14, XD2.15, XD2.16, XD2.17
Logic PNP or NPN
Voltage level 0–24 V DC
Voltage level, logic 0 PNP <5 V DC
Voltage level, logic 1 PNP >10 V DC
Voltage level, logic 0 NPN
(2)
>19 V DC
Voltage level, logic 1 NPN
(2)
<14 V DC
Maximum voltage on input 28 V DC
Pulse frequency range 0–110 kHz
(Duty cycle) minimum pulse width 4.5 ms
Input resistance, R
i
Approximately 4 kΩ
1
Terminals XD2.14 and XD2.15 can also be programmed as output.
2
Except STO input terminal XD2.19.
All digital inputs are galvanically isolated from the supply voltage (PELV) and other high-voltage terminals.
10.6.7 Pulse/Encoder Inputs
Programmable pulse/encoder inputs 2/1
Terminal number (pulse inputs)
XD2.15
(1)
, XD2.17
Terminal number (encoder inputs)
(2)
XD2.16, XD2.17
Maximum frequency at terminals XD2.15, XD2.16, XD2.17 (push-pull driven) 110 kHz
Maximum frequency at terminals XD2.15, XD2.16, XD2.17 (open collector) 5 kHz
Maximum frequency at terminals XD2.15, XD2.16, XD2.17 4 kHz
Voltage level See Control Input/Output and Control Data.
Maximum voltage on input 28 V DC
Input resistance, R
i
Approximately 4 kΩ
Specifications
Operating Guide | VLT® AQUA Drive FC 202
AQ262141056213en-000101 / 130R0882 | 173
