USB plug
(1)
USB type B plug
1
Connection to the PC is carried out via a standard host/device USB cable.
The USB connection is galvanically isolated from the supply voltage (PELV) and other high-voltage terminals; however, the USB ground
connection is not galvanically isolated from ground. Use only an isolated laptop as PC connection to the USB connector on the drive.
10.6.2 STO Terminal XD2.19 (Terminal XD2.19 is Fixed PNP Logic)
STO Terminal XD2.19
(1) (2)
Voltage level 0–24 V DC
Voltage level, logic 0 PNP <4 V DC
Voltage level, logic 1 PNP >20 V DC
Maximum voltage on input 28 V DC
Typical input current at 24 V 50 mA rms
Typical input current at 20 V 60 mA rms
Input capacitance 400 nF
1
For more information about Terminal XD2.19 (Terminal 37 on the drive module) and Safe Torque Off, see the design guide.
2
When using a contactor with a DC coil inside with STO, it is important to make a return way for the current from the coil when turning it off. This can be done by using a freewheel
diode (or, alternatively, a 30 V or 50 V MOV for quicker response time) across the coil. Typical contactors can be bought with this diode.
All digital inputs are galvanically isolated from the supply voltage (PELV) and other high-voltage terminals.
10.6.3 Control Card, 24 V DC Output
Terminal number XD2.10, XD2.11
Output voltage 24 V +1, -3 V
Maximum load 200 mA
The 24 V DC supply is galvanically isolated from the supply voltage (PELV), but has the same potential as the analog and digital inputs
and outputs.
10.6.4 Control Card, +10 V DC Output
Terminal number XD2.6
Output voltage 10.5 V ±0.5 V
Maximum load 15 mA
The 10 V DC supply is galvanically isolated from the supply voltage (PELV) and other high-voltage terminals.
10.6.5 Digital Outputs
Programmable digital/pulse outputs 2
Terminal number
(1)
XD2.14, XD2.15
Specifications
Operating Guide | VLT® AQUA Drive FC 202
AQ262141056213en-000101 / 130R0882
172 | Danfoss A/S © 2018.10
