100 mm (3.9 in)
200 mm (7.9 in)
400 mm (15.8 in)
10.9.2 D9h Enclosed Drive Dimension
e30bu121.10
400 (15.8)
2000
55
(78.7)
100 (3.9)
400 (15.8)
600 (23.6)
(2.2)
1
2 3
4
1 Passive harmonic filter/line reactor cabinet
3 Sine-wave cabinet
2 D9h drive cabinet
4 Standard pedestal
Illustration 72: Dimensions for D9h Enclosure with Standard Pedestal
Specifications
Operating Guide | VLT® AQUA Drive FC 202
AQ262141056213en-000101 / 130R0882
186 | Danfoss A/S © 2018.10
