11.6.5 Passive Harmonic Filter Losses
Table 130: Power Losses for Passive Harmonic Filter Option, 380–500 V (Losses Shown in Watts)
Model 380–440 V 441–500 V
– NO HO NO HO
N90K 1083 841 1083 841
N110 1284 1083 1284 1083
N132 1511 1284 1511 1284
N160 1704 1511 1704 1511
N200 1814 1704 1814 1704
N250 2242 1814 1980 1814
N315 2302 2242 2242 1980
N355 2498 2302 2302 2242
N400 2613 2498 2498 2302
N450 2838 2613 2613 2498
N500 3160 2838 2838 2613
Table 131: Power Losses for Passive Harmonic Filter Option, 525–690 V (Losses Shown in Watts)
Model 525–550 V 551–690 V
– NO HO NO HO
N90K 3406 2689 2689 2151
N110 4302 3406 3406 2689
N132 5199 4302 4302 3406
N160 6454 5199 5199 4302
N200 8246 6454 6454 5199
N250 10308 8246 8246 6454
N315 10308 10308 10308 8246
N355 7768 6872 6872 5498
N400 10995 6872 7768 6872
N500 9919 9919 8605 7768
N560 10995 9919 9919 8605
N630 13744 10995 10995 9919
N710 13744 13744 13744 10995
Appendix
Operating Guide | VLT® AQUA Drive FC 202
AQ262141056213en-000101 / 130R0882
202 | Danfoss A/S © 2018.10
