10.1.2 Electrical Data, 525–690 V AC

Table 82: Electrical Data, Mains Supply 3x525–690 V AC

FC 202 N110 N132 N160 N200

High/normal overload

High overload=150% or 160% torque for a

duration of 60 s. Normal overload=110% tor-

que for a duration of 60 s.

HO NO HO NO HO NO HO NO

Typical shaft output at 550 V [kW] 75 90 90 110 110 132 132 160

Typical shaft output at 575 V [hp] 100 125 125 150 150 200 200 250

Typical shaft output at 690 V [kW] 90 110 110 132 132 160 160 200

Enclosure size D9h D9h D9h D10h

Output current (3-phase)

Continuous (at 550 V) [A] 113 137 137 162 162 201 201 253

Intermittent (60 s overload) (at 550 V) [A] 170 151 206 178 243 221 301 278

Continuous (at 575/690 V) [A] 108 131 131 155 155 192 192 242

Intermittent (60 s overload) (at 575/690 V) [A] 162 144 197 171 233 211 288 266

Continuous kVA (at 550 V) [kVA] 103 125 125 147 147 183 183 230

Continuous kVA (at 575 V) [kVA] 108 131 131 154 154 191 191 241

Continuous kVA (at 690 V) [kVA] 129 157 157 185 185 230 229 289

Maximum input current

Continuous (at 525 V) [A] 109 132 132 156 156 193 193 244

Continuous (at 575/690 V) [A] 104 126 126 149 149 185 185 233

Maximum number and size of cables per phase

- Mains [mm

(AWG)]
