Enclosed drive D9h D10h E5h E6h
Height [mm (in)]
(1)
– 2100 (82.7) 2100 (82.7) 2100 (82.7)
Width [mm (in)] – 600 (23.6) 600 (23.6) 600 (23.6)
Depth [mm (in)] – 600 (23.6) 600 (23.6) 600 (23.6)
Weight [kg (lb)] – 380 (838) 380 (838) 380 (838)
Sine-wave filter cabinet D9h D10h E5h E6h
Height [mm (in)]
(1)
2100 (82.7) 2100 (82.7) 2100 (82.7) 2100 (82.7)
Width [mm (in)] 600 (23.6) 600 (23.6) 1200 (47.2) 1200 (47.2)
Depth [mm (in)] 600 (23.6) 600 (23.6) 600 (23.6) 600 (23.6)
Weight [kg (lb)]
dU/dt filter cabinet D9h D10h E5h E6h
Height [mm (in)]
(1)
– – 2100 (82.7) 2100 (82.7)
Width [mm (in)]
(3)
– – 400 (15.8) 400 (15.8)
Depth [mm (in)] – – 600 (23.6) 600 (23.6)
Weight [kg (lb)] – – 240 (529) 240 (529)
Top entry/exit cabinet D9h D10h E5h E6h
Height [mm (in)]
(1)
2100 (82.7) 2100 (82.7) 2100 (82.7) 2100 (82.7)
Width [mm (in)]
(3)
400 (15.8) 400 (15.8) 400 (15.8) 400 (15.8)
Depth [mm (in)] 600 (23.6) 600 (23.6) 600 (23.6) 600 (23.6)
Weight [kg (lb)] 164 (362) 164 (362) 164 (362) 164 (362)
1
Cabinet height includes standard 100 mm (3.9 in) pedestal. A 200 mm (7.9 in) or 400 mm (15.8 in) pedestal is optional.
2
Without options.
3
The E5h and E6h enclosures contain 2 sine-wave cabinets. The provided width is the total of both cabinets.
3.6 Control Compartment and Local Control Panel
3.6.1 Control Compartment Overview
The control compartment is a self-contained space that can be accessed without opening the drive enclosure. The control
compartment contains the following:
• Local control panel (LCP).
• Terminals for option cards.
• Optional auxiliary components and related wiring.
• Terminals for internal connections.
• Terminals for control cabling.
• Product nameplate.
• Buttons and indicator lights (on the exterior door).
For wiring and terminal descriptions, see 5.7.2 Control Compartment Interior View.
Product Overview
Operating Guide | VLT® AQUA Drive FC 202
AQ262141056213en-000101 / 130R0882 | 25
Danfoss A/S © 2018.10
