4.8 Airflow Rates
Table 21: Airflow Rates for D9h Enclosure
Cabinet
Back-channel fan [m
3
/hr (cfm)] Drive module top fan [m
3
/hr (cfm)] Cabinet door fan [m
3
/hr (cfm)]
PHF/line reactor 450 (265) – –
Drive 420 (250) 102 (60) 150 (90)
dU/dt – – –
Sine-wave 900 (530) – –
Top entry/top exit – – –
Table 22: Airflow Rates for D10h Enclosure
Cabinet
Back-channel fan [m
3
/hr (cfm)] Drive module top fan [m
3
/hr (cfm)] Cabinet door fan [m
3
/hr (cfm)]
PHF/line reactor 450 (265) – –
Input options – – 510 (310)
Drive 840 (500) 204 (120) 315 (185)
dU/dt – – –
Sine-wave 900 (530) – –
Top entry/top exit – – –
Table 23: Airflow Rates for E5h Enclosure
Cabinet
Back-channel fan [m
3
/hr (cfm)] Drive module top fan [m
3
/hr (cfm)] Cabinet door fan [m
3
/hr (cfm)]
PHF/line reactor 765 (450) – –
Input options – – 510 (310)
Drive 994 (585) 595 (350) 335 (200)
dU/dt 665 (392) – –
Sine-wave 2x900 (530) – –
Top entry/top exit – – –
Table 24: Airflow Rates for E6h Enclosure
Cabinet
Back-channel fan [m
3
/hr (cfm)] Drive module top fan [m
3
/hr (cfm)] Cabinet door fan [m
3
/hr (cfm)]
PHF/line reactor 1285 (755) – –
Input options – – 510 (310)
Drive 1053–1206 (620–710) 629 (370) 430 (255)
dU/dt 665 (392) – –
Sine-wave 2x900 (530) – –
Top entry/top exit – – –
Mechanical Installation
Operating Guide | VLT® AQUA Drive FC 202
AQ262141056213en-000101 / 130R0882 | 35
Danfoss A/S © 2018.10
