Table 5: Brake Option Codes
Character position Option code Description
15 X No brake IGBT
B Brake IGBT
T Safe Torque Off
U Brake IGBT + Safe Torque Off
Table 6: Mains Option Codes
Character position Option code Description
16–17 MX None
M1 Fusible disconnect
M2 Non-fusible disconnect
M3 Circuit breaker (MCCB)
M4 Contactor
M5 AC reactor
M6 Fuses
MA Fusible disconnect + contactor
MB Non-fusible disconnect + contactor
MC AC reactor + fusible disconnect
MD AC reactor + fusible disconnect + contactor
ME AC reactor + non-fusible disconnect
MF AC reactor + circuit breaker (MCCB)
MG AC reactor + contactor
MH AC reactor + non-fusible disconnect + contactor
Table 7: Output Filter Option Codes
Character position Option code Description
18 X None
D dU/dt
S Sine-wave
C Common-mode
1 Common-mode + dU/dt
2 Common-mode + sine-wave
