Danfoss VLT AQUA Drive FC 202 User Manual

Table 8: Extra Cabinet Option Codes
Character position Option code Description
19 X None
4 400 mm (15.8 in), left-hand side
6 600 mm (23.6 in), left-hand side
A 400 mm (15.8 in), right-hand side
B 600 mm (23.6 in), right-hand side
Table 9: Cable Infeed Option Codes
Character position Option code Description
20 X Bottom
T Top
L Mains top, motor bottom
M Mains bottom, motor top
Table 10: Auxiliary Power Supply Codes
Character position Option code Description
21 X No supply
1 230 V AC external
2 230 V AC internal
4 230 V AC internal + 24 V DC internal
5 230 V AC external + 24 V DC internal
6 120 V AC external
7 120 V AC internal
8 120 V AC internal + 24 V DC internal
9 120 V AC external + 24 V DC internal
Table 11: Back-channel Cooling Option Codes
Character position Option code Description
22 X Bottom in, top out
1 Back in, back out
C Back in, top out
D Bottom in, back out
N None
Product Overview
Operating Guide | VLT® AQUA Drive FC 202
AQ262141056213en-000101 / 130R0882
22 | Danfoss A/S © 2018.10

Danfoss VLT AQUA Drive FC 202 Specifications

General

Brand	Danfoss
Model	VLT AQUA Drive FC 202
Category	DC Drives
Language	English
