Table 12: Auxiliary Function Option Codes
Character posi-
tion
Option
code
Description
23–24 XX No auxiliary options
A1 AC socket+cabinet light
A2 Extended I/O terminals
A3 Cabinet heater
A4 Motor heater control
A5 Insulation monitor
AA AC socket + cabinet light + extended I/O terminals
AB AC socket + cabinet light + cabinet heater
AC AC socket + cabinet light + motor heater control
AD AC socket + cabinet light + insulation monitor
AE AC socket + cabinet light + extended I/O terminals + cabinet heater
AF AC socket + cabinet light + extended I/O terminals + motor heater control
AG AC socket + cabinet light + extended I/O terminals + insulation monitor
AH AC socket + cabinet light + extended I/O terminals + cabinet heater + motor heater control
AI AC socket + cabinet light + extended I/O terminals + cabinet heater + insulation monitor
AJ AC socket + cabinet light + extended I/O terminals + motor heater control + insulation monitor
AK AC socket + cabinet light + extended I/O terminals + cabinet heater + motor heater control + in-
sulation monitor
AL AC socket + cabinet light + cabinet heater + motor heater control
AM AC socket + cabinet light + cabinet heater + insulation monitor
AN AC socket + cabinet light + cabinet heater + motor heater control + insulation monitor
AO AC socket + cabinet light + motor heater control + insulation monitor
AP Extended I/O terminals + cabinet heater
AQ Extended I/O terminals + motor heater control
AR Extended I/O terminals + insulation monitor
AS Extended I/O terminals + cabinet heater + motor heater control
AT Extended I/O terminals + cabinet heater + insulation monitor
AU Extended I/O terminals + cabinet heater + motor heater control + insulation monitor
AV Extended I/O terminals + motor heater control + insulation monitor
AW Cabinet heater + motor heater control
AX Cabinet heater + insulation monitor
AY Cabinet heater + motor heater control + insulation monitor
AZ Motor heater control + insulation monitor
Product Overview
Operating Guide | VLT® AQUA Drive FC 202
AQ262141056213en-000101 / 130R0882 | 23
Danfoss A/S © 2018.10
