Danfoss VLT AQUA Drive FC 202

Example:
e30bu147.10
A The 4 mounting points at the base of the pedestal
C The 2 mounting points at the upper back of the cabinet
B The 2 mounting points at the front base of the pedestal
D The 2 mounting points in the mounting bracket
Illustration 19: Cabinet Mounting Points
