Dell PowerEdge XE9640 - Page 148

Figure 130. Installing the intrusion switch module
Figure 131. Intrusion switch cabling diagram for Intel GPU configurations
From
To
RIO-INTRUSION_DET1 (Intrusion switch connector on
system board)
Intrusion Switch on the Storage tray
148 Installing and removing system components
