Installing and removing system components
Topics:
• Safety instructions
•
Before working inside your system
• After working inside your system
• Recommended tools
• Optional front bezel
• System cover
• Cooling fans
• Cable cover
• Fan board
• Drives
• Drive backplane
• Optional BOSS-N1 module
• Versabay board (VSB)
• Storage tray
• Cable routing for Intel GPU Configurations
• Cable routing for NVIDIA GPU Configurations
• Power supply unit
• System memory
• Turtle shell
• Expansion cards and expansion card risers
• Lower brace cover
• Processor and Direct Liquid Cooling module
• Intrusion switch
• System battery
• Trusted Platform Module
• Optional OCP card
• System board
• LOM card and rear I/O board
• Control panel
• Intel GPU module, CBB (Carrier Base board) cold plate, GPU board, GPU cold plates, Power Distribution Board (PDB)
• NVIDIA GPU module, GPU board, GPU cold plates, PCIe Switch Board (PSB), Power Distribution Board (PDB)
• Manifold module
Safety instructions
NOTE:
Whenever you need to lift the system, get others to assist you. To avoid injury, do not attempt to lift the system by
yourself.
CAUTION: Ensure that two or more people lift the system horizontally from the box and place it on a flat
surface, rack lift, or into the rails.
WARNING: Opening or removing the system cover while the system is powered on may expose you to a risk of
electric shock.
WARNING: Do not operate the system without the cover for a duration exceeding five minutes. Operating the
system without the system cover can result in component damage.
7
Installing and removing system components 59
