3. Install the lower brace cover.
4. Reconnect all the cables onto the system board. For more information, see Cabling diagram.
5. Install the risers.
6. Install the storage tray.
7. Install the VSB cables on the system board.
8. Follow the procedure listed in the After working inside your system.
.
Removing the sensor tray for Intel GPU configurations
Prerequisites
1. Follow the safety guidelines listed in the Safety instructions.
2. Follow the procedure listed in the Before working inside your system .
3. Remove the storage tray.
4. Remove the risers.
5. Remove the VSB cables from the system board.
6. Remove lower brace cover.
7. Disconnect all the cables from the system board and make note of all the cable connections. For more information, see
Cabling diagram.
8. Disconnect the liquid cooling tubes 11 and 12 from the Manifold for DLC module and keep in on the system board and make
sure do not damage any connectors on the system board.
9. Slide out the system board tray.
10. Make sure to wear gloves for remove sensor tray to prevent hands touch sensor cables directly.
Figure 186.
11. Do not touch the sensor tray cable directly.
190
Installing and removing system components
