Figure 39. Installing a drive into the drive carrier
Next steps
Install the drive carrier.
Drive backplane
This is a service technician replaceable part only.
Drive backplane
Depending on your system configuration, the drive backplanes that are supported are listed here:
Table 63. Supported backplane options
System Supported hard drives options
PowerEdge XE9640 2.5-inch (x4) NVMe backplane
Figure 40. 4 x 2.5-inch NVMe drive backplane
1.
PCIE connector (BP_DST_PB1) 2. SATA connector (BP_DST_SA1)
3. PCIE connector (BP_DST_PA1) 4. Power connector (BP_PWR_1)
80 Installing and removing system components
