Ports and connectors specifications
USB ports specifications
Table 15. PowerEdge XE9640 USB specifications
Front Rear
USB port type No. of ports USB port type No. of ports
USB 2.0-compliant port One USB 3.0-compliant port One
iDRAC Direct port
(Micro-AB USB 2.0-
compliant port)
One USB 2.0-compliant ports One
NOTE: The micro USB 2.0 compliant port can only be used as an iDRAC Direct or a management port.
Optional LOM and OCP NIC 3.0 specifications
The PowerEdge XE9640 system supports the shared LOM feature (iDRAC port redirect) on optional 2x1GbE LOM and on
optional OCP NIC 3.0 adapters.
NOTE: LOM and OCP are optional and one has to be selected for any configuration.
VGA ports specifications
The PowerEdge XE9640 system supports One DB-15 VGA port on the front panel.
iDRAC9 port specifications
The PowerEdge XE9640 system supports One RJ45 iDRAC9 ethernet port on the rear of the system.
Video specifications
The PowerEdge XE9640 system supports integrated Matrox G200 graphics controller with 16 MB of video frame buffer.
Table 16. Supported video resolution options
Resolution Refresh rate (Hz) Color depth (bits)
1024 x 768 60 8, 16, 32
1280 x 800 60 8, 16, 32
1280 x 1024 60 8, 16, 32
1360 x 768 60 8, 16, 32
1440 x 900 60 8, 16, 32
1600 x 900 60 8, 16, 32
1600 x 1200 60 8, 16, 32
1680 x 1050 60 8, 16, 32
1920 x 1080 60 *(RB) 8, 16, 32
1920 x 1200 60 *(RB) 8, 16, 32
26 Technical specifications
