NOTE: Heat dissipation is calculated using the PSU wattage rating.
NOTE: When selecting or upgrading the system configuration, to ensure optimum power utilization, verify the system
power consumption with the Dell Energy Smart Solution Advisor available at Dell.com/ESSA.
Table 8. PSU Efficiency Levels
Efficiency Targets by Load PSU Efficiency Levels
Form Factor Output Class 10% 20% 50% 100%
Redundant 86
mm
2800 W (Input
230 AC)
Titanium 90.00% 94.00% 96.00% 94.00%
Cooling fan specifications
The PowerEdge XE9640 system supports up to four sets of high-performance gold (HPR) hot-swappable cooling fans.
NOTE: XE9640 includes dual fan module form factor. One set of fan module includes two fan body with one fan connector.
Table 9. Cooling fan specifications
Fan type Abbrev
iation
Also known
as
Label color Label image
High
Performance
Gold fan
HPR
Very High
Performance
High Performance
Gold Grade
Figure 17. HPR fan
NOTE: For more information about the supported fan configuration or matrix, see Thermal Restriction Matrix.
Supported operating systems
The PowerEdge XE9640 supports the following operating systems:
●
Canonical Ubuntu Server LTS
● Red Hat Enterprise Linux
System battery specifications
The PowerEdge XE9640 system uses one CR 2032 3.0-V lithium coin cell battery.
Expansion card riser specifications
The PowerEdge XE9640 system supports up to four PCI express (PCIe) slots (Gen5 full-height, half-length cards) on the
system board.
Technical specifications
