Dell PowerEdge XE9640 system
configurations and features
The Dell PowerEdge XE9640 is 2-socket, 2U server that supports:
● Two 4
th
Generation Intel Xeon Scalable Processors with up to 56 cores per processor
● Four Intel Data Center Max GPU series 1550 600 W OAM GPUs, fully interconnected with XeLink with Only 16 DIMM slots
are supported out of 32 DIMMs (with 8 DIMMs per processor),
● Four NVIDIA H100 700 W SXM GPUs fully interconnected with NVlink with 8 DIMMs, 16 DIMMs and 32 DIMMs for XE9640
NVIDIA GPU supported systems
● Up to 4 PCIe slots (4 x16 Gen5)
● 100% Liquid cooling system
● Up to 4 x 2.5-inch NVMe SSD drives, 61.44 TB max for XE9640 Intel GPU and NVIDIA GPU supported systems
NOTE: For more information about how to hot swap NVMe PCIe SSD U.2 device, see the Dell Express Flash NVMe
PCIe SSD User's Guide at https://www.dell.com/support > Browse all products > Infrastructure > Data Center
Infrastructure > Storage Adapters & Controllers > Dell PowerEdge Express Flash NVMe PCIe SSD > Select This
Product > Documentation > Manuals and Documents.
NOTE: All instances of SAS, SATA drives are referred to as drives in this document, unless specified otherwise.
CAUTION: Do not install GPUs, network cards, or other PCIe devices on your system that are not validated
and tested by Dell. Damage caused by unauthorized and invalidated hardware installation will null and void the
system warranty.
Topics:
• System configurations - front view for PowerEdge XE9640
• System configurations - rear view for PowerEdge XE9640
• System configurations - inside view for PowerEdge XE9640
• Air and Liquid Cooling Infrastructure Requirements
• Locating the Express Service Code and Service Tag
• System information label
• Rail sizing and rack compatibility matrix
System configurations - front view for PowerEdge
XE9640
Figure 1. 4 x 2.5-inch NVMe SSD drives for XE9640 Intel and NVIDIA GPU configuration
2
Dell PowerEdge XE9640 system configurations and features 9
