Table 73. System board jumpers and connectors(continued)
Item Connector Description
3. J_SL11 PCIe connector 11 (applicable only for
XE9640 with Intel GPU)
4 J_SL12 PCIe connector 12 (applicable only for
XE9640 with Intel GPU)
5. J_OCP1 OCP NIC 3.0 connector
6. BAT1 Coin cell battery
7. J1 XDP connector
8. P23 TPM connector
9. J_DSL1 PCIe connector DSL1
10. J_PSU1_SIG PSU1 signal connector
11. J_SL14 PCIe connector 14 (applicable only for
XE9640 with Intel GPU)
12. J_SL13 PCIe connector 13 (applicable only for
XE9640 with Intel GPU)
13. J_LOM1 LOM connector
14. J_SL15 PCIe connector 15 (applicable only for
XE9640 with Intel GPU)
15. J_R1 Riser 1
16. J_IDSDM1 IDSDM/Internal USB connector
17. J_SIG_PWR_0 Power connector 0 - use for BP only
18. J_FRONT_VIDEO1 Front VGA
19. BOSS_PWR BOSS card power
20. J_SL16 PCIe connector 16
21. PWR1_B For Riser 1 GPU power and signal cable
22. PWR1_A For right BBU power cable
23. A9, A1, A15, A7, A11, A3, A13, A5 DIMM for CPU 1 channels A, B, C, D
24. J_SL8_CPU1_PA4 PCIe connector 8
25. P_RGT_CP Right control panel connector
26. J_FAN_2U6 Fan 6 connector
27. J_SIG_PWR_2_2U Power connector 2 - use for BP only
28. J_SIG_PWR_0B PCIe connector
29. J_SL7 PCIe connector 7
30. J_FAN_2U5 Fan 5 connector
31. J_SL4 PCIe connector 4
32. U_CPU1 Processor 1
33. J_FAN_2U4_1U5_6 Fan 4 connector
34. J_SL3 PCIe connector 3
35. A8, A16, A2, A10, A6, A14, A4, A12 DIMMs for CPU 1 channels H, G, F, E
36. J_SIG_PWR__2U Power connector 1 - use for BP only
258 Jumpers and connectors
