Delta AS Series User Manual

 AS-FFTP01
With its own standalone communication port, the extension card can work independently and can be set as a
MODBUS TCP server, Client or EtherNet/IP Adapter. After installing the extension card, go to the HWCONFIG
in ISPSoft to set up the communication.
Ethernet communication interface
Item
Specifications
Connector type
RJ-45*2
Transmission speed
10/100BASE-T (X) full duplex, switched Ethernet
Cable
CAT5e (up to 100 m)
Communication protocol
Modbus TCP Server, Client and EtherNet/IP Adapter
Isolation
1500 VAC
Micro SD
Item Specifications
Applicalbe SD card
Micro SD card
Capacity
Max.<= 2TB (SD/SDHC/SDXC)
Speed class rating
Class 10 (C1)
Busbar interface
High Speed (25MB/s)
 It is suggested to use the Micro SD with 32GB capacity and Class10 rating
 AS-FECAT
This communication card can work independently and does NOT occupy the communication port of PLC CPU.
It can act as Modbus TCP Server and EtherCAT Master. After AS-FECAT is installed, you can go to
HWCONFIG from ISPSoft for editing in the Function Card 2 section.
Ethernet communication interface
Item
Specifications
Connector type
RJ-45*2
Transmission speed
10/100BASE-T (X) full duplex, switched Ethernet (before EtherCAT
Master enabled)
Cable
CAT5e (up to 100 m)
Communication protocol
Modbus TCP Server and EtherCAT Master
Isolation
1500 VAC
Send Quote Requests to info@automatedpt.com
Call +1(800)985-6929 To Order or Order Online At Deltaacdrives.com
Send Quote Requests to info@automatedpt.com
Call +1(800)985-6929 To Order or Order Online At Deltaacdrives.com

Delta AS Series Specifications

General

Series	AS Series
Power Supply	24VDC
Cooling Method	Natural convection
Programming Language	Function Block Diagram (FBD)
Communication Interface	Ethernet, RS-232, RS-485
Output Voltage	24V DC
Output Current	2A
Operating Temperature	55°C
Storage Temperature	70°C
Protection Features	Overvoltage
Certifications	CE, UL
