8.1.2.12 Edit Area – Update
To update the module parameters, first you need to be in the online mode. Select the module that you want to update
its parameters and then click the
Update
button. This functionality is only available for digital IO modules, analog IO
modules and network modules.
8.1.2.13 Show or Hide the Display
Click or to hide the display area and after that only its tab remains shown. Move your cursor to the tab to
have the hidden display area shown. Click to pin and lock the display area to keep it shown.
