Delta AS Series User Manual

Index Subindex Object name Data type Attribute
Default
value
H’02 The third mapped object Unsigned 32 bits RW 0x20000310
H’03 The fourth mapped object Unsigned 32 bits RW 0x20000410
H’1601
-- RxPDO2 mapping parameter
H’00 Number of valid subindex Unsigned 8 bits RW 0
H’01 The first mapped object Unsigned 32 bits RW 0
H’01 The second mapped object Unsigned 32 bits RW 0
H’02 The third mapped object Unsigned 32 bits RW 0
H’03 The fourth mapped object Unsigned 32 bits RW 0
H’1602
-- RxPDO3 mapping parameter
H’00 Number of valid subindex Unsigned 8 bits RW 0
H’01 The first mapped object Unsigned 32 bits RW 0
H’01 The second mapped object Unsigned 32 bits RW 0
H’02 The third mapped object Unsigned 32 bits RW 0
H’03 The fourth mapped object Unsigned 32 bits RW 0
H’1603
-- RxPDO4 mapping parameter
H’00 Number of valid subindex Unsigned 8 bits RW 0
H’01 The first mapped object Unsigned 32 bits RW 0
H’01 The second mapped object Unsigned 32 bits RW 0
H’02 The third mapped object Unsigned 32 bits RW 0
H’03 The fourth mapped object Unsigned 32 bits RW 0
H’1604
-- RxPDO5 mapping parameter
H’00 Number of valid subindex Unsigned 8 bits RW 0
H’1604
H’01
The first mapped object
Unsigned 32 bits
RW
0
H’01 The second mapped object Unsigned 32 bits RW 0
H’02 The third mapped object Unsigned 32 bits RW 0
H’03 The fourth mapped object Unsigned 32 bits RW 0
H’1605
-- RxPDO6 mapping parameter
H’00 Number of valid subindex Unsigned 8 bits RW 0
H’01 The first mapped object Unsigned 32 bits RW 0
H’01 The second mapped object Unsigned 32 bits RW 0
H’02 The third mapped object Unsigned 32 bits RW 0
