Delta AS Series - Page 57

 Spring clamp/MIL connector terminal block UB-10-IO32D for AS332T-A/AS332P-A/AS324MT-A
23 6.
24 35.
26.9
33.7
101
1
2
Unit: mm
Number Name Description
1 Terminal block for output Terminal block
2 40-pin MIL connector Connects the module and the wiring module
Note: It is suggested to use simple test for input and output points. Its right-side cannot be conntected to
the same terminal block typed module, e.g. 64 points DIO module to prevent two terminal blocks from
interfering with each other.
