AX-Series Motion Controller Instructions Manual Chapter 2
492
 Inputs/Outputs
Name
Function
Data Type
Setting Value
Timing to Take Effect
- - - - -
 Function
 To generate KeyPoint for DMC_CamKeyPointWrite FB, the Slider move from TDC to BDC.
 Troubleshooting
Error
Code
Description Contents Corrective Action
0
No Error
-
-
 Sample Program
 Input refMachParameters.lrRLength, refMachParameters.lrLLength (Link > 2* Crank).
 Set bExecute to True.
 Wait bDone to change to True. The FB will create Key points data.
