Delta AX Series User Manual

AX-Series Motion Controller Instructions Manual Appendix A
545
Error code Description Contents Corrective Action
0x18881
DMC_GM_AXIS_GROUP_INIT_FAIL
ED
Axis group initialization failed.
1. use the axis group in the device
tree as the input to the instruction.
2. Re-run the function block.
0x18882
DMC_GM_INVALID_AXIS_IN_AXIS_
GROUP
Invalid axes in axis group.
1. Make sure all the axes specified
in the parameter setting exist in
the device tree.
2. Download the program again.
3. Re-run the function block.
0x18883
DMC_GM_DUPLICATE_
AXIS_IN_AXIS_GROUP
Duplicated axes in axis group.
1. Make sure there’s no duplicated
axis specified in the parameter
setting.
2. Download the program again.
3. Re-run the function block.
0x18884
DMC_GM_AXIS_
ALREADY_IN_OTHER_
ENABLED_AXIS_GROUP
Some axes have been already
existed in another enabled axis
group.
1.
Make sure the specified axis does
not exist in other enabled axis
group or disable the axis group
which has the axis in it.
2. Re-run the function block.
0x18885
DMC_GM_AXIS_GROUP_INVALID_
TASK_
CONFIGURATION
Task is not configured correctly.
1. Make sure that the Setting Values
of bus cycle task meet the
requirement.
(Type: Cyclic, Interval: > 1ms)
2. Download the program again.
3. Re-run the function block.
0x18886
DMC_GM_AXIS_GROUP_COUNT_R
EACH_LIMIT
The axis group count has
reached the limit.
1. To activate more groups, make
sure the number of activated axis
group is less than the max.value.
2. Re-run the function block.
0x18890
DMC_GM_AXIS_GROUP_INVALID_
PARAMETER
Invalid axis group parameter
After confirming that Parameter input
pin has correct readable and writable
parameters, re-run the function block.
0x18891
DMC_GM_AXIS_GROUP_CANT_WR
ITE_PARAMETER_DURING_GROUP
_ENABLED
Cannot modify parameter
during the axis group is
enabled.
After using DMC_GroupDisable to
disable this axis group, re-run the
function block.
0x18892
DMC_GM_AXIS_GROUP_INVALID_
PARAMETER_SETTING
Invalid axis group parameter
After confirming that lrValue input pin
has correct parameter Setting Value,
re-run the function block.
0x1889A
DMC_GM_INVALID_IDENT_IN_GRO
UP
The value of the input pin
"IdentInGroup" is not within the
legal range.
Correct the value of the input pin
"IdentInGroup". (Range starts at 1)
Re-run the function block.
0x1889B
DMC_GM_AXIS_NOT_PART_OF_AX
IS_GROUP
The specified axis does not
belong to this axis group and
cannot be removed.
Make sure that the specified single
axis is included in the axis group.
Re-run the function block.
0x1889C
DMC_GM_AXIS_GROUP_CANNOT_
ADD_SAME_AXIS
It is forbidden to add the same
axis to the axis group multiple
times.
Confirm that the specified single axis
is not currently included in the axis
group.
Re-run the function block.
0x188B5
DMC_CKPW_WRITE
AMOUNT_OUTOFRANGE
WriteAmount input error
Check and correct the input value of
WriteAmount before Run the function
block.
