29
Chapter 2 Milling
Preparing for Milling
CAM Settings Necessary for Milling
The settings shown below must be included in the milling data used by this machine.
Workpiece
Set the type of workpiece to use in milling.
" P.29 "Usable Workpieces and Sizes"
Adapter ID
Set the ID of the adapter to use in milling.
" P.31 "Adapter/Adapter ID"
Milling bur
Set all the milling burs to use in milling.
" P.30 "Usable Milling Bur Sizes"
Milling bur stocker number
Set the number of the milling bur stocker in which the milling
burs will be loaded.
" P.45 "Step 3: Setting the Milling Bur"
Workpiece
Usable Workpieces and Sizes
Zirconia, wax, PMMA, composite resin, PEEK, gypsum, glass-ber-reinforced resin, and CoCr sintered metal
Type Size
Disk type
(with step)
Step section: 98.5 mm (diameter), 10 mm (height)
Body section: 95 mm (diameter), 35 mm max. (height)
Pin type
Pin diameter: 6 mm
ø5.9 ± 0.02
