DGSHAPE DWX-52DCi - Step 3: Setting the Milling Bur

Milling bur positioner
Step 3: Setting the Milling Bur
Required Items
Milling bur Milling bur positioner Milling bur holder Mounting screw
Hexagonal
screwdriver
Procedure
A
Attach the milling bur holder to the milling bur positioner.
1 Insert the milling bur holder oriented as shown in the gure and attach it so that it
reaches the back of the hole.
Milling bur holder
Orient this part with the
screw hole facing up.
2 Slide the milling bur through the milling bur holder and determine the proper position.
Insert the milling bur as shown in the gure and make sure that both ends are within the areas of the
milling bur positioner holes.
3 Secure the mounting screw using the hexagonal screwdriver.
Both ends of the milling bur
are within the A and B areas.
Starting Milling
45
Chapter 2 Milling
