Machine Trouble
82
Chapter 4 FAQ
Compressed Air Does Not Come Out
Does the operation require
compressed air?
Compressed air is only supplied during some
operations, such as when the spindle is
rotating or when replacing the milling bur.
—
Is the regulator properly
connected and are the pressure
settings correctly congured?
Check the connection. Check that the
pressure has been set to 0.2 MPa. If the set
pressure of the regulator is zero, compressed
air will not be supplied.
P.32
Is the knob at the bottom of the
regulator open?
The compressed air will escape if the knob at
the bottom of the regulator is open.
P.74
Automatic Correction Fails
Is the automatic correction jig,
detection pin, or ATC magazine
dirty?
Clean away any grime on the automatic
correction jig, the detection pin, and the ATC
magazine. These items being dirty due to a
buildup of milling waste or the like may impede
correct sensor operation, making detection
impossible.
P.65
Is the automatic correction jig
properly attached?
Verify that the automatic correction jig is
properly attached.
P.67
Is the detection pin properly
attached?
Verify that the detection pin is properly
attached. Check the position of the milling bur
holder on the detection pin.
Refer to the "Setup Guide" ("Dimensional
Drawings" (Detection Pin Dimensions)).
Setup
Guide
