Preparing for Milling
31
Chapter 2 Milling
Adapter/Adapter ID
Workpieces are used while set in adapters labeled with adapter IDs. Manage the work situations of workpieces by
using CAM to specify the adapter ID. Once you have started using a workpiece, do not remove it from the adapter
until you are nished using it. If you remove a workpiece that you have started using from the adapter, you will no
longer be able to manage information such as the position information in the CAM data.
When You Want to Use Six or More Adapters
If you want to use six or more adapters, purchase optional products. (Up to 26 adapters [IDs: A to Z] can be managed.)
" P.56 "Purchasing Additional Adapters"
Workpiece
Adapter
Adapter base
Adapter cap
Adapter ID
